5-GALLON C-DUCT PUMP CART

DO NOT USE WITH FUEL

DO NOT MIX FLUIDS

PART NUMBERING SIGN

5GB03BTC-PM-(Signify Oil)

WEIGHTS AND DIMENSIONS

- Product Dimension
  42 1/2” x 18 1/2” x 24 1/2”

- Net Weight (Dry)
  57 lbs. (25.854 kg.)

Shipping Carton
20 1/2” x 18 1/2” x 40”

HIGH PRESSURE UNIT

- Operating Temperature Range
  -40°F to 120°

- Fluid Capacity
  5-Gallon (18.9 L)

- Pressure Output Single Acting
  5000 PSI (34473.78 KPA)

Hose Length
15 Foot

EACH SYSTEM INCLUDES

5-Gallon Capacity Container
Steel Cart
Translucent Polyethylene Container
Bolt-on Container
5000 psi. Hand Pump
15 Foot Hose
Color-Coded End Caps & Fluid Signage
Compatible Seals and Hoses
Serial Number for easy tracking
Quick Disconnect Couplers available

SYSTEM FEATURES

Adjustable Pressure Relief Valve
Factory Set at 4000 psi.
Steel Cart
Easy to read Signage
All Weather Performance
Environmentally Safe

5-GALLON C-DUCT PUMP CART

DO NOT USE WITH FUEL

DO NOT MIX FLUIDS

PART NUMBERING SIGN

5GB03BTC-(Signify Oil)

WEIGHTS AND DIMENSIONS

- Product Dimension
  42 1/2” x 18 1/2” x 24 1/2”

- Net Weight (Dry)
  57 lbs. (25.854 kg.)

Shipping Carton
20 1/2” x 18 1/2” x 40”

HIGH PRESSURE UNIT

- Operating Temperature Range
  -40°F to 120°

- Fluid Capacity
  5-Gallon (18.9 L)

- Pressure Output Single Acting
  5000 PSI (34473.78 KPA)

Hose Length
15 Foot

EACH SYSTEM INCLUDES

5-Gallon Capacity Container
Steel Cart
Translucent Polyethylene Container
Bolt-on Container
5000 psi. Hand Pump
15 Foot Hose
Color-Coded End Caps & Fluid Signage
Compatible Seals and Hoses
Serial Number for easy tracking
Quick Disconnect Couplers available

SYSTEM FEATURES

Adjustable Pressure Relief Valve
Factory Set at 4000 psi.
Steel Cart
Easy to read Signage
All Weather Performance
Environmentally Safe

5-GALLON C-DUCT PUMP CART

DO NOT USE WITH FUEL

DO NOT MIX FLUIDS

PART NUMBERING SIGN

10483 OPEN C-DUCT

WEIGHTS AND DIMENSIONS

- Product Dimension
  42 1/2” x 18 1/2” x 24 1/2”

- Net Weight (Dry)
  57 lbs. (25.854 kg.)

Shipping Carton
20 1/2” x 18 1/2” x 40”

HIGH PRESSURE UNIT

- Operating Temperature Range
  -40°F to 120°

- Fluid Capacity
  5-Gallon (18.9 L)

- Pressure Output Single Acting
  5000 PSI (34473.78 KPA)

Hose Length
15 Foot

EACH SYSTEM INCLUDES

5-Gallon Capacity Container
Steel Cart
Translucent Polyethylene Container
Bolt-on Container
5000 psi. Hand Pump
15 Foot Hose
Color-Coded End Caps & Fluid Signage
Compatible Seals and Hoses
Serial Number for easy tracking
Quick Disconnect Couplers available

SYSTEM FEATURES

Adjustable Pressure Relief Valve
Factory Set at 4000 psi.
Steel Cart
Easy to read Signage
All Weather Performance
Environmentally Safe

2-GALLON C-DUCT PUMP

DO NOT USE WITH FUEL

DO NOT MIX FLUIDS

PART NUMBERING SIGN

10482 OPEN C-DUCT

WEIGHTS AND DIMENSIONS

Product Dimension
16” x 13” x 16”
Net Weight (Dry)
30 lb. (13.607)
Shipping Carton
18” x 14” x 12”

HIGH PRESSURE UNIT

Operating Temperature Range
-40°F to 120°
Fluid Capacity
2 Gallon (7.6 L)
Pressure Output Single Acting
5000 PSI (34473.78 kpa)
Hose Length
15 Foot
Filter 10 Micron Nominal (
(3 Micron Available)

EACH SYSTEM INCLUDES

2 Gallon Capacity Container
Aluminum Cover and Base
Translucent Polyethylene Container
5000 psi. Hand Pump
15 Foot Hose
Color-Coded End Caps & Fluid Signage
Compatible Seals and Hoses
Serial Number for easy tracking
Quick Disconnect Couplers available

SYSTEM FEATURES

Adjustable Pressure Relief
Valve Factory set at 4000 psi.
Easy to read Signage
All Weather Performance
Environmentally Safe
Ergonomically Designed

TRANSFER PAC (T-PAC)

DO NOT USE WITH FUEL

DO NOT MIX FLUIDS

VIEW SHOWS UNIT WITH HOSE REEL. NOT A PART OF KIT.

PART NUMBERING SYSTEM

EXAMPLE: 10380 ENGINE OIL
10381 SKYDROL

WEIGHTS AND DIMENSIONS

Product Dimension
11 1/2” x 5 1/2” x 9 1/4”
Net Weight (Dry)
21 lb. (9.5 kg)
SHIPPING PALLET

LOW PRESSURE UNIT

Operating Temperature Range
-40°F to 120°
Fluid Capacity
0-10 gpm (0-40 kg)
Pressure Output
0-100 psi (0-400 KPA)
Pump, Gear Air or Nitrogen
Hose Length
15 Foot
Filter (Spin-on)
10 Micron Nominal 3 Micron Available

EACH SYSTEM INCLUDES

Pneumatic Motor with Gear Pump
Spin-on Filter
Safety Shut-off Valve
Bung Assembly Kit
Flow Control Nozzle with Drip-Less Spout
Nozzle Holder
15 Foot Hose

Color-Coded End Caps & Fluid Signage
Compatible Seals and Hoses
Serial Number for easy tracking
Quick Disconnect Couplers Available
Compatible with most Fluids
Environmentally Safe

THE SERVICE STATION

DO NOT USE WITH FUEL

DO NOT MIX FLUIDS

55 Gallon Drum platform
(Can be moved by a forklift)

PART NUMBERING SYSTEM

Part Number 10676

WEIGHTS AND DIMENSIONS

Product Dimension
49.50” x 41.00” x 47.00”
Net Weight (Dry)
600 lbs. (272.15 kg)
Shipping Carton – Pallet

LOW PRESSURE UNIT

Operating Temperature Range
-40°F to 120°
Fluid Capacity
55 Gallon (208.20 L)
Pressure Output
0-110 PSI (49.90 KPA)
Hose Length 50 Foot
Filter (SPIN-ON)
10 Micron Nominal (3 Micron Available)

EACH SYSTEM INCLUDES

Maximum load capacity of 880 lbs.
Equipped with a single jaw clamp assembly Hydraulic Drum Lift
Drip Pan
Digital metering valve
Hose Reel with 50-foot hose
10 Micron OR 3 Micron Filtration System
Pneumatic Filtration System

Emergency Shut-Off Valve
All Steel Construction
Air Driven Gear Pump Available and Drum bung kit
Drum bung kit
Overflow container
Drum not included

We will design and build all systems to meet the customers specifications.

25-GALLON MOUNTABLE ELECTRIC OIL DISPENSER

PART NUMBERING SYSTEM

Part Number: 25-OIL TYPE
EXAMPLE:
25E-2197 OR 25E-SKYDROL

WEIGHTS AND DIMENSIONS

- Product Dimension
  20” x 42” x 14”

- Net Weight (Dry)
  75 lb. (34.019 KG)

SHIPPING PALLET

LOW PRESSURE UNIT

Operating Temperature Range
-40°F to 120°
12 Volt Pump
40 AMP Circuit Breaker
Fluid Capacity
25 Gallon (94.63 L)
Pressure Output
20 PSI.@ 10 Gallons /Minute
Hose Length
20 Foot
Filter (Spin-On)
10 Micron Nominal(3 Micron Available)

EACH SYSTEM INCLUDES

25-GALLON CAPACITY CONTAINER
TRANSLUCENT POLYETHYLENE CONTAINER
Bolt-on Unit
Meter (Quarts or Liters)
Color-Coded End Caps & Fluid Signage
Compatible Seals and Hoses
SERIAL NUMBER FOR EASY TRACKING
Closed Containment System

SYSTEM FEATURES

SELF-FILLING UNIT
QUICK COUPLER FILL PORT
CONTAINER VENT DRYING FILTER
Closed Containment System
Unit can be mounted on a Pickup, Lift truck or Electric Cart
Easy to read Signage
All Weather Performance
Environmentally Safe
Ergonomically Designed

5-GALLON MOUNTABLE ELECTRIC UNIT

DO NOT USE WITH FUEL

DO NOT MIX FLUIDS

PART NUMBERING SYSTEM

PART NUMBER 5E-OIL TYPE
and the Oil Sign.
EXAMPLE: 5E-2197 OR 5E-SKYDROL

WEIGHTS AND DIMENSIONS

- PRODUCT DIMENSION:
  24-1/2” x 18-1/2” x 10”

- NET WEIGHT (DRY)
  75 lbs.

SHIPPING CARTON PALLET

LOW PRESSURE UNIT

- 12 VOLT PUMP

- 40 AMP CURCUIT BREAKER

- FLUID CAPACITY
  5-GALLONS (18.9 L)

- PRESSURE OUTPUT
  20 PSI AT 3-5 GALLONS/MINUTE

- 40 AMP CIRCUIT BREAKER

- HOSE LENGTH
  20 FT

SPIN-ON FILTER
10 MICRON NOMINAL
(3 MICRON IS AVAILABLE)

EACH SYSTEM INCLUDES

5-GALLON CAPACITY CONTAINER
TRANSLUSCENT POLYETHYLENE CONTAINER
METER (QUARTS OR LITER)
COLOR-CODED FLUID SIGNAGE
COMPATIBLE SEALS AND HOSES
SERIAL NUMBER FOR EASY TRACKING

SYSTEM FEATURES

3-5 GALLONS PER MINUTE AT 20 PSI
SELF-FILLING UNIT
QUICK COUPLER FILL PORT
CONTAINER VENT DRYING FILTER
HOSE LENGTH 20 FEET
CLOSED CONTAINMENT
UNIT CAN BE MOUNTED TO PICKUP TRUCK, LIFT TRUCK OR TRAILER AND ELECTRIC CARTS

Engine Servicing 20 Gallon Towable

TWO PUMP SYSTEM

DO NOT USE WITH FUEL

DO NOT MIX FLUIDS

PART NUMBERING SYSTEM

Part Number 10749
ENGINE OIL AVAILABLE

WEIGHTS AND DIMENSIONS

Product Dimension
48” x 45” x 36”
Net Weight (Dry)
175 lbs. (79.4kg)
Shipping Carton – Pallet

TWO PUMP SYSTEM

PUMP ONE

Operating Temperature Range
-40°F to 120°
Fluid Capacity
20 Gallon (7.6 L)
Pressure Output
175 PSI (1206.5 KPA)
Volume per Stroke
¼ PINT (120 cc)
Hose ½” DIA.
Hose Length
15 Foot
Filter (SPIN-ON)
10 Micron Nominal (3 Micron Available)
Designed for cold weather use

PUMP TWO

Pressure Output
1-110 PSI (30.28 – 37.85 KPA)
Pump Air or Nitrogen
Hose ½” DIA.
Hose Length
15 Foot
Filter (SPIN-ON)
10 Micron Nominal (3 Micron Available)
Designed for cold weather use

EACH SYSTEM INCLUDES

20 GL Towable Cart, MIL-PRF-7808
Heavy Duty Steel Frame with Standard Pintle Hook Tow Ring
Translucent Polyethylene Container
USMDI Hi-Tech double seal- Hand Pump
15 Foot X 1/2 Inch. Hose
Color- coded Fluid Signage
Compatible Seals and Hoses

30 mph Wheels and Bearings
Front Caster with Foot Activated Brake
Serial Number for easy Tracking
Compatible With most fluids
Environmentally Safe
Aircraft Quick Couplers are Supplied by the Customer.

5-GALLON TOWABLE PNEUMATIC SERVICING UNIT

DO NOT USE WITH FUEL

DO NOT MIX FLUIDS

PART NUMBERING SYSTEM

PART NUMBER ( 5TP – OIL TYPE)
5TP-2197 OR 5TP-SKYDROL

WEIGHTS AND DIMENSIONS

Product Dimension
48” x 45” x 36”
Net Weight (Dry)
150 lbs. (49.89kg)
Shipping Carton – Pallet

LOW PRESSURE UNIT

Operating Temperature Range
-40°F to 120°
Fluid Capacity
5-Gallon (7.6 L)
Pressure Output
1-110 PSI (30.28 – 37.85 KPA)
Pump Air or Nitrogen
Hose Length
15 Foot
Filter (SPIN-ON)
10 Micron Nominal (3 Micron Available)

EACH SYSTEM INCLUDES

5- Gallon Capacity Container
Translucent Polyethylene Container
Pneumatic Gear Pump
Flow Control Nozzle
15 Foot Hose
Color-Coded End Caps & Fluid Signage
Compatible Seals and Hoses
Heavy Duty Steel Frame

Standard Pintle Hook Tow Ring
30 mph Wheel and Bearings
Front Caster With Foot Activated Brake
Serial Number for easy tracking
Quick Disconnect Couplers available
Compatible with most Fluids
Environmentally Safe

Engine Servicing 20-Gallon Towable

PART NUMBER

20 GL Towable Cart, MIL-PRF-7808

WEIGHTS AND DIMENSIONS

Empty Weigh: 145 lb.
MIL-PRF: 20ST-MIL-PRF-7808
NSN: 3920016817104 – FLUID CART UOM: EA

SYSTEM FEATURES

Heavy Duty Steel Frame with Standard Pintle Hook Tow Ring
Color: 26173 Gray Semi-Gloss- 53.65-1.4-4.3 Ocean Gray
Translucent Polyethylene Container
USMDI Hi-Tech double seal- Hand Pump
15 Foot X 1/2 Inch. Hose‑MIL‑DTL‑8794
Color- coded Fluid Signage
Compatible Seals and Hoses
2 Brackets, for Jerry Cans -2

Jerrycan Overflow Container
1 1/2 Gallon with Metal Cap and Clear Hose, #8 JIC Fittings, 8 feet NO COUPLER
30 mph Wheels and Bearings
Front Caster with Foot Activated Brake
Serial Number for easy Tracking
Compatible With most fluids
Environmentally Safe
Aircraft Quick Couplers are Supplied by the Customer

20-GALLON TOWABLE OIL DISPENSER WITH OVERFLOW CONTAINER

DO NOT USE WITH FUEL

DO NOT MIX FLUIDS

PART NUMBERING SYSTEM

Part Number ( 20T – OIL TYPE)
20T-2197 OR 20T-SKYDROL

WEIGHTS AND DIMENSIONS

Product Dimension
48” x 45” x 36”
Net Weight (Dry)
150 lbs. (49.89kg)
Shipping Carton – Pallet

LOW PRESSURE UNIT

Operating Temperature Range
-40°F to 120°
Fluid Capacity
20-Gallon (7.6 L)
Pressure Output
175 PSI (1206.5 KPA)
Volume per Stroke
¼ PINT (120 cc)
Hose Length
15 Foot
Filter (SPIN-ON)
10 Micron Nominal (3 Micron Available)

EACH SYSTEM INCLUDES

20-Gallon Capacity Container
Translucent Polyethylene Container
Overflow Container
Standard USMDI Hi-Tech Double-Seal Hand Pump
15 Foot Hose
Color-Coded End Caps & Fluid Signage
Compatible Seals and Hoses
Heavy Duty Steel Frame

Standard Pintle Hook Tow Ring
30 mph Wheel and Bearings
Front Caster With Foot Activated Brake
Serial Number for easy tracking
Quick Disconnect Couplers available
Compatible with most Fluids
Environmentally Safe

AVAILABLE OPTIONS

Fluid Discharge Meter
Pressure Relief Valve
In-line Water Stop Filter
Closed System Kit

STANDARD 5-GALLON TOWABLE OIL DISPENSER WITH OVERFLOW CONTAINER

DO NOT USE WITH FUEL

DO NOT MIX FLUIDS

PART NUMBERING SYSTEM

Part Number ( 5ST – OIL TYPE)
EXAMPLE:
5ST-2197 OR 5ST-SKYDROL

WEIGHTS AND DIMENSIONS

Product Dimension
42 1/2” x 28 1/2” x 30”
Net Weight (Dry)
110 lb. (49.89kg)
Shipping Carton – Pallet

LOW PRESSURE UNIT

Operating Temperature Range
-40°F to 120°
Fluid Capacity
5-Gallon (7.6 L)
Pressure Output
175 PSI (1206.5 KPA)
Volume per Stroke
¼ PINT (120 cc)
Hose Length
15 Foot
Filter (SPIN-ON)
10 Micron Nominal (3 Micron Available)

EACH SYSTEM INCLUDES

5-Gallon Capacity Container
Translucent Polyethylene Container
Overflow Container
Standard USMDI Hi-Tech Double-Seal Hand Pump
15 Foot Hose
Color-Coded End Caps & Fluid Signage
Compatible Seals and Hoses
Heavy Duty Steel Frame

Standard Pintle Hook Tow Ring
30 mph Wheel and Bearings
Front Caster With Foot Activated Brake
Serial Number for easy tracking
Quick Disconnects available
Compatible with most Fluids
Environmentally Safe

AVAILABLE OPTIONS

Fluid Discharge Meter
Pressure Relief Valve
In-line Water Stop Filter
Closed System Kit

BASIC 5-GALLON TOWABLE FLUID DISPENSER

DO NOT USE WITH FUEL

DO NOT MIX FLUIDS

PART NUMBERING SYSTEM

Part Number ( 5BT – OIL TYPE)
5BT-2197 OR 5BT-SKYDROL

WEIGHTS AND DIMENSIONS

Product Dimension
42 1/2” x 28 1/2” x 30”
Net Weight (Dry)
110 lbs. (49.89kg)
Shipping Carton – Pallet

LOW PRESSURE UNIT

Operating Temperature Rang
-40°F to 120°
Fluid Capacity
5-Gallon (7.6 L)
Pressure Output
175 PSI (1206.5 KPA)
Volume per Stroke
¼ PINT (120 cc)
Hose Length
15 Foot
Filter (SPIN-ON)
10 Micron Nominal (3 Micron Available)

EACH SYSTEM INCLUDES

5-Gallon Capacity Container
Translucent Polyethylene Container
Standard USMDI Hi-Tech Double-Seal Hand Pump
Hand Pump
15 Foot Hose
Color-Coded End Caps & Fluid Signage
Compatible Seals and Hoses
Heavy Duty Steel Frame

Standard Pintle Hook Tow Ring
30 mph Wheel and Bearings
Front Caster With Foot Activated Brake
Serial Number for easy tracking
Quick Disconnect Couplers available
Compatible with most Fluids
Environmentally Safe

AVAILABLE OPTIONS

Fluid Discharge Meter
Pressure Relief Valve
In-line Water Stop filter
Closed System Kit

DO NOT MIX FLUIDS

PART NUMBERS

20-2380
20-2197
20-ENGINE OIL
20-5606
20-MOBIL JET II
20-SKYDROL
20-HYDRAULIC OIL
20-HYJET IV
OTHERS AVAILABLE

SIGN

EXXON 2380
2197
ENGINE OIL
5606
MOBIL JET II
SKYDROL
HYDRAULIC OIL
HYJET IV

SEAL

FKM
FKM
FKM
FKM
FKM
EPDM
EPDM
EPDM

LOW PRESSURE UNIT

FLUID CAPACITY 20 GALLONS (75.7 L)
PRESSURE OUTPUT 175 PSI (854.4 kPa)
OUTPUT PER STROKE 1/4 PINT (120cc)
HOSE LENGTH 15 FT
STANDARD FILTER 10 MICRON NOMINAL
(3 MICRON IS AVAILABLE

WEIGHTS AND DIMENSIONS

PRODUCT DIMENSION: 23-3/4” x 40-1/2” x 24-1/2”
NET WEIGHT (DRY) 37 lbs. (16.81 kg.)
GROSS WEIGHT 74.5 lbs. (33.86 kg.)
SHIPPING CARTON 42-1/2” x 18-1/2” x 24-1/2″

EACH SYSTEM INCLUDES

20 GALLON CAPACITY CONTAINER
TRANSLUSCENT POLYETHYLENE CONTAINER
DOUBLE-SEAL PUMP HEAD
COLOR-CODED FLUID SIGNAGE
COMPATIBLE SEALS AND HOSES
SERIAL NUMBER FOR EASY TRACKING

SERVICE POINTS

ENGINE
APU
CSD/IDG
HYDRAULIC SYSTEMS

AVAILABLE OPTIONS

FLUID DISCHARGE METER
IN-LINE WATER STOP FILTER
CLOSED SYSTEM KIT
3 MICRON FILTER

DO NOT USE WITH FUEL

DO NOT MIX FLUIDS

PART NUMBERING SYSTEM

Print Unit Number ( 5 – OIL TYPE)
EXAMPLE:
5-2197 OR 5-SKYDROL

WEIGHTS AND DIMENSIONS

Product Dimension
23 3/4” x 40 1/2” x 24 1/2”
Net Weight (Dry)
37.2 lbs. (16.81kg)
Gross Weight
74.5lbs. (33.86 kg)
Shipping Carton
42 1/2” x 18 1/2” x 241/2”

LOW PRESSURE UNIT

Operating Temperature Range:
-40°F to 120°
Fluid Capacity:
5-Gallon (18.5 L)
Pressure Output:
175 PSI (1206.5 KPA)
Volume per Stroke:
¼ PINT (120 cc)
Hose Length:
15 Foot
Filter:
10 Micron Nominal
(3 Micron Available)

EACH SYSTEM INCLUDES

5-Gallon Capacity Container
Steel Cart
Translucent Polyethylene Container
Bolt-on Container
Double-Seal Pump Head
15 Foot Hose
Color-Coded Fluid Signage
Compatible Seals and Hoses
Serial Number for easy tracking
Quick Disconnects available

AVAILABLE OPTIONS

Fluid Discharge Meter
In-line Water Stop filter
Closed System Kit

DO NOT USE WITH FUEL

DO NOT MIX FLUIDS

PART NUMBERING SYSTEM

Print Unit Number ( 2 – OIL TYPE)
EXAMPLE:
2-2197 OR 2-SKYDROL

WEIGHTS AND DIMENSIONS

Product Dimension
12 3/16” x 9 1/4” x 18”
Net Weight (Dry)
15.2 lbs. (6.75kg)
Gross Weigh
18 lbs. (8.18 kg)Shipping
Carton
14” x 9 1/4” x 18 3/4”

LOW PRESSURE UNIT

Operating Temperature Range
-40°F to 120°
Fluid Capacity
2 Gallon (7.6 L)
Pressure Output
175 PSI (1206.5 KPA)
Volume per Stroke
¼ PINT (120 cc)
Hose Length
7 Foot
Filter
10 Micron Nominal
(3 Micron Available)

EACH SYSTEM INCLUDES

2 gallon Capacity Container
Translucent Polyethylene Container
Double-Seal Pump Head
7 Foot Hose
Color-Coded Fluid Signage
Compatible Seals and Hoses
Serial Number for easy tracking
Quick Disconnect Couplers available

AVAILABLE OPTIONS

Fluid Discharge Meter
In-line Water Stop filter
Closed System Kit

SYSTEM FEATURES

Compact
All Weather Performance
Environmentally Safe
No-spill
Ergonomically Designed
Lightweight – Easy to Handle

1-Gallon Oil Servicing Dispenser, Low Pressure, Unit

DO NOT USE WITH FUEL

DO NOT MIX FLUIDS

PART NUMBERING SYSTEM

PART NUMBER 1-OIL TYPE and the Oil Sign.
EXAMPLE:
1-2197 OR 1-SKYDROL

WEIGHTS AND DIMENSIONS

Product Dimension
10” x 12” x 4”
Net Weight (Dry)
15 lbs. (6.803kg)
Shipping Carton
10” x 10” x 24”

LOW PRESSURE UNIT

Operating Temperature Range
-40°F to 120°
Fluid Capacity
1 Gallon (3.79 L)
Pressure Output
¼ PINT (120 cc)
Hose Length
7 Foot
Filter 10 Micron
Nominal3 micron Available

EACH SYSTEM INCLUDES

One Gallon Capacity Container
Container Vent with Check Valve and Drying Filter
Translucent Polyethylene Container
7 Foot Hose
Sealed Fill Cap
Color-Coded Fluid Signage
Compatible Seals and Hoses
Serial Number for easy tracking
Shoulder Strap

You may be interested in…

Your cart is currently empty!

New in store

PART NUMBERING SYSTEM

WEIGHTS AND DIMENSIONS

LOW PRESSURE UNIT

EACH SYSTEM INCLUDES

SYSTEM FEATURES

5-GALLON C-DUCT PUMP CART

DO NOT USE WITH FUEL

PART NUMBERING SIGN

WEIGHTS AND DIMENSIONS

HIGH PRESSURE UNIT

EACH SYSTEM INCLUDES

SYSTEM FEATURES

5-GALLON C-DUCT PUMP CART

PART NUMBERING SIGN

WEIGHTS AND DIMENSIONS

HIGH PRESSURE UNIT

EACH SYSTEM INCLUDES

SYSTEM FEATURES

5-GALLON C-DUCT PUMP CART

PART NUMBERING SIGN

WEIGHTS AND DIMENSIONS

HIGH PRESSURE UNIT

EACH SYSTEM INCLUDES

SYSTEM FEATURES

2-GALLON C-DUCT PUMP

PART NUMBERING SIGN

WEIGHTS AND DIMENSIONS

HIGH PRESSURE UNIT

EACH SYSTEM INCLUDES

SYSTEM FEATURES

TRANSFER PAC (T-PAC)

PART NUMBERING SYSTEM

WEIGHTS AND DIMENSIONS

LOW PRESSURE UNIT

EACH SYSTEM INCLUDES

THE SERVICE STATION

PART NUMBERING SYSTEM

WEIGHTS AND DIMENSIONS

LOW PRESSURE UNIT

EACH SYSTEM INCLUDES

25-GALLON MOUNTABLE ELECTRIC OIL DISPENSER

PART NUMBERING SYSTEM

WEIGHTS AND DIMENSIONS

LOW PRESSURE UNIT

EACH SYSTEM INCLUDES

SYSTEM FEATURES

5-GALLON MOUNTABLE ELECTRIC UNIT

PART NUMBERING SYSTEM

WEIGHTS AND DIMENSIONS

LOW PRESSURE UNIT

EACH SYSTEM INCLUDES

SYSTEM FEATURES

Engine Servicing 20 Gallon Towable

TWO PUMP SYSTEM

PART NUMBERING SYSTEM

WEIGHTS AND DIMENSIONS

TWO PUMP SYSTEM

PUMP ONE

PUMP TWO

EACH SYSTEM INCLUDES

5-GALLON TOWABLE PNEUMATIC SERVICING UNIT

PART NUMBERING SYSTEM

WEIGHTS AND DIMENSIONS

LOW PRESSURE UNIT

EACH SYSTEM INCLUDES

Engine Servicing 20-Gallon Towable

PART NUMBER

WEIGHTS AND DIMENSIONS

SYSTEM FEATURES

20-GALLON TOWABLE OIL DISPENSER WITH OVERFLOW CONTAINER

DO NOT USE WITH FUEL

PART NUMBERING SYSTEM

WEIGHTS AND DIMENSIONS

LOW PRESSURE UNIT

EACH SYSTEM INCLUDES

AVAILABLE OPTIONS
